Continuous Integration and Continuous Deployment (CI/CD) pipelines play a pivotal role in facilitating streamlined software development. Yet, as these pipelines become increasingly crucial, the imperative to protect them from vulnerabilities becomes more pronounced. This in-depth investigation focuses on addressing a prominent risk identified in the OWASP Top-10 CI/CD Security Risks: Poisoned Pipeline Execution (PPE).

What is Poisoned Pipeline Execution (PPE)

According to OWASP Top-10 CI/CD Security Risks, “Poisoned Pipeline Execution (PPE) risk refers to the ability of an attacker with access to source control systems – and without access to the build environment – to manipulate the build process by injecting malicious code/commands into the build pipeline configuration, essentially ‘poisoning’ the pipeline and running malicious code as part of the build process”

In a few words, Poisoned Pipeline Execution (PPE) is produced when the attacker can modify the pipeline logic.

There are two variants:

  • Direct PPE (D-PPE): In a D-PPE scenario, the attacker modifies the CI config file in a repository they have access to, either by pushing the change directly to an unprotected remote branch on the repo, or by submitting a PR with the change from a branch or a fork. Since the CI pipeline execution is defined by the commands in the modified CI configuration file, the attacker’s malicious commands ultimately run in the build node once the build pipeline is triggered.
  • Indirect PPE (I-PPE): In certain cases, the possibility of D-PPE is not available to an adversary with access to an SCM repository (e.g. if the pipeline is configured to pull the CI configuration file from a separate, protected branch in the same repository). In such a scenario, rather than poisoning the pipeline itself, an attacker injects malicious code into files referenced by the pipeline (for example: scripts referenced from within the pipeline configuration file)

In both cases, GitHub will execute the modified pipeline with no need for a previous review or approbation.

Early detection of PPE

How can we detect this type of vulnerability?

Let’s see this example pipeline :

name: PR CI

on:
  pull_request:
    branches: [ main ]

env:
  MY_SECRET: ${{ secrets.MY_SECRET }}

jobs:
  pr_build_test_and_merge:
    runs-on: ubuntu-latest

    steps:
      # checkout PR code
      - name: Checkout repository
        uses: actions/checkout@v4

      # Simulation of a compilation
      - name: Building ...
        run: |
          echo $MY_SECRET
          mkdir ./bin
          touch ./bin/mybin.exe

      # Simulation of running tests
      - name: Running tests ...
        id : run_tests
        run: |
          echo Running tests..
          chmod +x runtests.sh
          ./runtests.sh "${{ github.event.pull_request.user.login }}" "${{ github.workflow }}"
          echo Tests executed.

And the content of a dummy shell script (runtests.sh):

#!/usr/bin/bash
echo "Executing Tests script [from user $1 at $2]" >> runtests.out
exit 0

The pipeline is quite simple: its aim is to provide the reviewer with some preliminary hints for the Pull Request (PR) acceptance process:

  • It’ will be triggered on pull_request (i.e. whenever a PR is created)
  • It checkout the PR code (i.e. the contributed code)
  • It will make the build
  • It will run tests on contributed code (e.g. by executing a shell script)

Steps #3 (make the build) and #4 (run test) will fail if the code does not compile or it fails to pass the tests. So, these steps act as a necessary, but not sufficient, condition to accept the PR. If successful, the repo admin will proceed to review the contributed code and, based on that, he/she will accept/reject/comment the PR.

Xygeni Scanner

Xygeni provides a CLI (the “Xygeni Scanner”) that can be embedded into a pipeline or run in a command-line. The Xygeni Scanner will process the pipelines to check for vulnerabilities and, if a GitHub PAT is provided, it will connect to GitHub to discover vulnerabilities at the org/repo level.

Xygeni Inventory

When we execute Xygeni Scanner on this repo, it discovers a useful set of assets (the Xygeni Inventory). The Inventory will be populated with many different types of CI/CD assets, such as:

  • The SCM System where the repo is stored
  • The SCM Plugins installed/used
  • The Code Repository itself
  • The SCM Organization where the repo belongs to
  • The CI/CD Pipelines and Jobs
  • The CI/CD System running the pipelines
  • IaC Resources defined into the repo
  • External Dependencies
  • etc..

In our example, we can filter the Inventory by some specific asset type (SCM- and CICD-related assets), so we can see that:

  • SCM system is GitHub Cloud
  • Repo is stored in GitHub Cloud and belongs to a specific GitHub Organization
  • There are two pipelines powered by GitHub (CI/CD system)
  • Every pipeline contains one specific step
Poisoned Pipeline Execution (PPE)

By selecting the above pipeline we can see some vulnerabilities:

  • At pipeline level, it is vulnerable to both Direct and Indirect PPE.

We can see the details of those Poisoned Pipeline Execution vulnerabilities

Poisoned Pipeline Execution (PPE)
Poisoned Pipeline Execution (PPE)

Xygeni detects that it’s vulnerable to D-PPE because it’s triggered on a Pull Request event and there are no additional security controls, so any repo user can modify the pipeline and those modifications will be executed without any review or approval.

In the same sense, Xygeni also detects that it’s vulnerable to I-PPE because of the call to the shell script from the pipeline: any repo user can modify the shell script and those modifications will be executed without any review or approval.

Do you want to know more?

Exploiting PPE

To exploit the PPE let’s consider a scenario where there are two kinds of repo users:

  • An internal user (an internal developer working on that repo), with write permissions on the repo
  • An external user (an outsourced developer working on that repo but with read permissions on the repo), i.e. not allowed to branch the repo and forced to work on a fork.

Let’s imagine that both are malicious attackers (or impersonated by a malicious actor). The repo contains some secret and both want to steal the repo secret and send it to a hacker-controlled server. To do it, they will take advantage of the Poisoned Pipeline Execution vulnerabilities of the pipeline.

In both cases (external and internal user), they open a Pull Request with the same modifications:

  • The pipeline and the shell script are modified to read the secret from the environment and send it to a hacker-controlled server

Modifications might be as follows:

Both users will create a Pull Request with the modifications. Upon creation of the PR, GitHub will execute both modifications (with no need of previous review or approval), resulting in the following:

Same for write and read users, in both cases D-PPE and I-PPE are executed, with the difference that the read user is not able to access the secrets. (!!!!)

This reason is because, in the case of a PR coming from a fork, GitHub does not allow access to the repo secrets. Although the read user cannot read the secrets, he/she can still run any other program. A typical attack example is creating PRs that download a crypto miner, so the GitHub runner will execute the crypto miner when executing a poisoned pipeline.

This is not a safe environment, of course!! What might the repo admin do to avoid it?

After some googling, the repo admin decides to modify the pipeline to be triggered on a pull_request_target event. Why? Because pipelines triggered on pull_request_target do not allow executing pipeline modifications, i.e. despite any user modification the “original” pipeline will be executed.

Following our example, the attack will be the same as before. What will happen then after this pipeline modification?

As expected, D-PPE is not executed but, because I-PPE is still there, the read user is now able to access the repo secret!!!

What is the reason that the read user now has access to secrets? Although the pipeline cannot be modified, it is still possible to modify the shell script. When a pipeline is triggered on pull_request_target, it will be executed in privileged mode so it will also be the shell script, resulting in the shell script having access to repo secrets!!

Preventive Measures

GitHub provides some measures to protect against malicious PRs.

Branch protection rules

With GitHub you can define Branch Protection Rules over selected branches.

For your protected branches, you can specify a policy that requires a pull request before merging (as well as additional conditions such as a required number of approvals, reviews from code owners, etc. )

A couple of conditions that deserves special consideration are:

  • Allow specified actors to bypass required pull requests”.
  • Do not allow bypassing the above settings

While most of the conditions add strictness to the policy, these ones relax the policy and that might entail an open door to malicious activities, for example, in the case that credentials are stolen by “privileged” actors.

Restrict GITHUB_TOKEN permissions (least-privilege)

Restrict the GitHub token permissions only to the required ones; this way, even in case the attackers succeed in compromising your pipeline, they won’t be able to do much.

Avoid string interpolation by using pipeline env variables

Whenever you use some input variables in your pipeline, be aware that they should be considered by default as “untrusted” data (their content is controlled by the end user). See https://securitylab.github.com/research/github-actions-untrusted-input/ and https://docs.github.com/en/actions/learn-github-actions/variables#using-the-vars-context-to-access-configuration-variable-values

You should always use environment variables to insert input variables inside scripts instead of using string interpolation.

Workflow runs and approval requirements

For public repos, GitHub allows to specify how to work with “external” PRs

GitHub Organization settings (“Org >> Settings >> Actions >> General”) let specify how to manage external PR’s:

By default, GitHub will require PR approval for 1st-time contributors, making malicious request attacks more complicated. Even so, the attacker might gain the project maintainers’ trust for example by contributing some innocent pull request before the real attack.

In this sense, the 3rd option (Requiring approval for all outside collaborators) adds a higher level of control.

For private repos, GitHub provides also helpful control both at the Organization- and Repo-level.

Run Workflows from Pull Requests” (not checked by default) allows users to run workflows from fork PRs (using a GITHUB_TOKEN with read-only permissions and with no access to secrets). By selecting this option together with the last one (“Require approval for fork PRs workflows”) , you can reach a similar policy to private repos (as shown above).

As we have seen in the PPE exploit from a read user, allowing running workflows from fork pull requests is unsafe!!

The remaining options (“Send write tokens to workflows from fork pull requests” and “Send secrets and variables to workflows from for pull requests”) decrease the security level applied to fork PRs.

You can define this fork policy either at the Organization Level or at Repo-level. If the policy is disabled at org-level, it cannot be enabled at the repo level. But, if the policy is enabled at org-level, it can be disabled at repo-level.

Recap

We hope you have seen the implications of having some pipeline vulnerable to Poisoned Pipeline Execution. It’s too easy to commit a vulnerable pipeline, and it’s difficult to write a safe one.

So it’s highly valuable to use the Xygeni Scanner to be aware of such vulnerabilities.

You cannot solve a vuln unless you are aware of its existence !!

But… There is still a pending question… How to avoid the I-PPE ?

This will be the subject of our next post  🙂 … Stay tuned !!
